This Tube Packing Machine is a high-tech product which successfully developed and designed by adopting advanced technology from abroad and strictly meet GMP requirement. PLC controller and color touch screen are applied and made it possible for programmable control of the machine.
Automatic Tube Filling And Sealing Machine is designed for plastic tube and multiple tube filling and sealing in cosmetic, pharmacy, foodstuff, adhesives etc industries
Main Features:
* Full automatic Ultrasonic tube filling and sealing machine could automatically finish tube feeding, registration mark identifying, filling, sealing with coding, end trimming, tube out feeding, fully automatic, save labor cost and lower production cost.
* Full automatic Ultrasonic tube filling and sealing machineis equipped with safety protection device and overload protection.
* Cam indexing system could position precisely for ten working stations.
*Adopts ultrasonic sealing technology, no need warm up time, more stable and neat sealing, no distortion and low reject rate less than 1%.
* Independent R &D for digital ultrasonic automatic tracking electrical control box, no need manual adjust the frequency, with power auto compensation function, avoiding the reduction of power after long time use. Could freely adjust the power based on tube material and size, stable and minimum the fault rate, extend the life span than the normal electrical box.
* PLC with touch screen control system with alarm system, could directly view the alarm information on the touch screen, could locate the problem and solve immediately.
* Made of 304 stainless Steel, acid and alkali resistance, corrosion resistance.
* No tube, no fill, no tube, no seal function, reducing the machine and mould loss.
*Adopts Anti-dripping filling nozzle.
| Function | Filling and sealing |
| Material | SUS316L & SS304 |
| Tube diameter | 15—60 |
| Tube length | 60—250(customizable |
| Filling volume | 5—400ml/pcs(adjustable |
| Product capacity | 1800—4000 pcs/h(adjustable |
| Working Position | 12 Pcs. One size one mold. |
Processing of filling and sealing machine:
Automatic feeding--Automatic print registration--Tube orientation checking--Tube filling-tube heated--Tube sealing&Code embossed--Tube cutting-Discharge
Application:
It can be used for pharmaceuticals, food products, cosmetics, and chemicals.
* Cosmetic: Face Cleaner, Hand Cream, Eye Cream, Sunscreen, Acne cream, Hair removal cream, Body lotion, Whitening Cream, etc.
* Food: Mayonnaise, Cheese, Peanut butter, etc.
* Pharmaceuticals: Ointment, Unguent, Paste, Toothpaste etc.
* Chemicals: Painting, Shoe polish etc.
Package & Delivery:
To ensure the quality of our service, we will follow the standard package upon delivery:
1. All products before delivery should be tested by assembly and commissioning engineers. Our salesman need to send the tested video to the customer to ensure working well of the machines. Precision parts need to be packed in film or carton.
2. All products are packed in wooden boxes. Firm
